Box opener sealing machine (box sealing machine and automatic box sealing machine)

A list of the contents of this article:

Main classification of box sealing machines

The sealing machine adopts instant adhesive tape to seal the carton, which is economical, fast and easy to adjust, can complete the upper and lower sealing action at one time, and can also use printing tape, which can improve the product image and is the first choice of automatic packaging for enterprises. It can be divided into semi-automatic sealing machine, pneumatic sealing machine, manual sealing machine, tape sealing machine, automatic bottom sealing machine, automatic sealing machine, four-corner sealing machine, folding cover sealing machine, corner sealing machine, side sealing machine and so on. The sealing machine produced is light and durable and easy to operate. Power source: 1p 110V 50Hz/60Hz 200W

Speed: 30 cases / min

Sealing size: L150-∞ W120-480H130-480 (mm)

Tape size: 48×72 (mm)

Kraft paper tape, BOPP tape

Machine size: L1090mm x W880mm x H1165mm

Transport size: L1628mm x W930mm x H1265mm

Gross weight / net weight: 220kg/170kg FX-03

* Power source: 1P 110V/220V 50Hz/60Hz 300W/470W

* Speed: 30 cases / min

* sealing size: L150 ~ ∞ W120mm 480H1200480 (mm)

* Tape size: 48mm 72 (mm) Kraft paper tape, BOPP tape

* Machine size: L1090mm x W890mm x H1280mm

* Transport size: L1200mm x W1050mm x H1435mm

* gross weight / net weight: 250kg/200kg. The folding cover sealing machine is suitable for automatically folding the upper cover of a certain specification carton and then sealing the upper and lower boxes with self-adhesive tape. in addition to manually adjusting the size of the carton, it can automatically fold the upper cover and seal the carton.

Machine characteristics

The main results are as follows: 1. Using high-strength grip PVC tape to drive both sides of the carton, the transmission runs smoothly and the tape is centering on the box.

2. it can be adjusted according to the size of the carton and realize the folding of the front, rear and side covers of the upper cover and the action of loading and unloading the carton.

3. It is the first in China to use pneumatic device to realize the automatic folding of the upper back cover and the side cover of the carton.

4. The tape sealing is smooth, firm, standardized and beautiful, and will not tear the box.

Product parameters

Conveying speed: 15m/min

Maximum packing size: W500 × H500mm

Minimum packing size: W150 × H120mm

Power supply: 220v/50-60Hz

Power consumption: 180W

Tape width: 48 60pm 76mm

External dimension: 1700 × 950x1690mm

Gas source: 5Kg/cmsup2

Machine weight: 250kg. Product characteristics

The main results are as follows: 1. The corner edge sealing machine is designed to be easy to operate, economical and durable, safe and the lowest failure rate.

2. Adjust the width and height of the machine manually according to the carton specifications.

3. Suitable for sealing cartons of the same specification at the same time

4. After the carton is sealed up and down in the middle of the front sealing machine, it enters the 90-degree corner machine, and the pushing plate is pushed into the sealing mechanism of the corner sealing machine.

5. the upper and lower corners of the carton are automatically sealed and smoothed at the same time; the sealing is beautiful, fast, labor-saving and efficient.

6. Install blade protection device to avoid accidental stabbing during operation.

Product parameters

FXJ-JB01

* Power source: 1p 110V/220V 50Hz/60Hz 1000W

* Speed: 12-15 cases / min

* sealing size: L200-500W350-700H200-500 (mm)

* Tape size: 48mm 72 (mm) Kraft paper tape, BOPP tape

* Machine size: L2200mm x W1280mm x H1400mm

* Transport size: L2250mm x W1330mm x H1600mm

* Gross weight / net weight: 550kg/480kg is manufactured by Taiwan technology and uses imported parts, electrical components and pneumatic components.

Adjust the width and height manually according to the carton specification

Suitable for cartons with side openings, such as beverages, floor tiles, etc.

Upper and lower belt drive, sealing on both sides, economical, fast and smooth

Equipped with knife protection device to avoid accidental stabbing during operation

It can work on a stand-alone machine, or can be used with an automatic assembly line.

FXJ-5050

* Power source: 1p 110V/220V 50Hz/60Hz 400W

* Speed: 12-15 cases / min

* sealing size: L200-550W150-480H127480 (mm)

* Tape size: 48mm 72 (mm) Kraft paper tape, BOPP tape

* Machine size: L1850mm x W988mm x H1370mm

* Transport size: L2000mm x W1050mm x H1570mm

* Gross weight / net weight: 360kg/300kg

Product name: FX-02 automatic folding cover sealing machine Technical parameters: power source: 1p 110V/220V 50Hz/60Hz 200W/400W Speed: 15 boxes / packing box size: L150 ~ ∞ W12000H1200450 (mm) Tape Dimensions: 48mm 72 (mm) Kraft Paper Tape, BOPP Tape Machine Dimensions: L1150mm x W1005mm x H1230mm Transport Dimensions: L1200mm x W1100mm x H1400mm Gross weight / net weight: 230kg/250kg

Detailed introduction:

When the automatic folding cover sealing machine cooperates with the assembly line operation, it is only necessary to fold the four bendable panels formed on the bottom surface of the carton, put the articles into the conveying track driven by belts on both sides, and the carton folding cover device on the upper side of the sealing machine starts, folding and sealing the box is completed at one time. When the size of the carton changes, the fully automatic machine positioning, automatic top folding, automatic timely transmission, no manual care, suitable for connecting to the automatic production line. Machine description:

GPA-50 left and right drive box sealing machine | one word sealing machine

1. Components:

The use of international advanced finishing equipment processing, selected international well-known brand accessories.

2. Technology:

Gurqi relies on more than ten years of independent R & D and design experience, and absorbs the advanced technology of international counterparts such as Japan and Germany in the sealing machine.

3. Appearance design:

① the dominant color of this sealing machine is beige, which is stylish and exquisite. The machine color suitable for the corresponding production line can also be configured according to the needs of customers.

② is light in size, complementary to pulleys and flexible in displacement, making it more convenient for installation and debugging.

4. Product technical parameters:

Product model: GPA-50

Conveying speed: 0-20m/min

Maximum packing size: l ∞ × W500 × H500mm

Minimum packing size: L150 × W150 × H120mm

Power supply: 220amp 380V 50Hz

Consumption function: 240W

Applicable tape: W48mm/60mm/75mm

Machine size: L1020 × W850 × H1350 (excluding front and rear roller frame)

Machine weight: 120kg

5. Powerful function of reasonable optimization:

① adjusts width and height manually according to carton specifications, which is simple, fast and convenient.

② belt drive on both sides, upper and lower sealing, economical, fast and smooth

6. industry-leading sealing performance:

① has stable performance, reliable quality, high sealing efficiency, strong applicability and long service life.

② is suitable for sealing light cartons after packing, and the sealing effect is smooth, standardized and beautiful.

③ adopts instant tape sealing, which is economical, fast and easy to adjust, and can complete the upper and lower sealing action at one time.

7. Protection design:

The performance of ① parts is precise and durable, the structure design is strict, the operation process is vibration-free, and the operation is stable and reliable.

② is equipped with blade protection device to avoid accidental stabbing during operation, safe production and efficient packaging. Tape sealing machine refers to the sealing of cartons with instant adhesive tape, which is economical and easy to adjust. It can complete the action of upper and lower sealing at one time, and printing tape and box opener can also be used to improve the product image. It is the first choice of automatic packaging enterprises. The key component of the box sealing machine is the driving motor. The greater the motor power, the better.

Characteristics of adhesive tape sealing machine:

1. The sealing machine is suitable for sealing and packing cartons, and can be used either individually or with an assembly line. it is suitable for chemical fiber industry, tobacco rebaking industry, pharmaceutical industry, publishing industry, refrigeration and air conditioning industry, home appliance industry, ceramic industry, food industry and so on.

two。 This sealing machine adopts instant adhesive tape to seal the carton, which is economical and easy to adjust. It can complete the upper and lower sealing action at one time, and the printing tape can be used to improve the product impression.

Technical parameters

Maximum sealing size: 500 × 600mm

Minimum sealing size: 150 × 90mm

Sealing tape width: 36mm, 48mm, 60mm

Workbench height: 500-750mm

Use tape: BOPP, Kraft paper, PVC tape

Sealing speed: 20 cartons / min (TEUs)

Power supply: 220V 50HZ 180W

External dimension: 1500 × 740 × 1425mm

Weight: 120kg function: ① automatically adjusts width and height according to different carton specifications

② side drive ten upper belt drive, suitable for heavy-duty, large carton use, to ensure that the upper and lower box sealing smoothly and quickly

③ stand-alone operation, suitable for small batch, multi-specification production.

Technical parameters

Conveying speed: 0-20m/min

Maximum packing size: l ∞ × W500 × H500mm

Minimum packing size: L150 × W150 × H150mm

Power supply: 220amp 380V 50Hz

Consumption function: 360W

Applicable tape: W48mm/60mm/75mm

Machine size: L1170 × W900 × H1350 (excluding front and rear roller frame)

Machine weight: 180kg

644df82e0bb23

Whose automatic sealing machine is the best to use?

Light including packing and sealing machine, economical and economical, high stability.

Automatic folding cover sealing machine

Light packaging is a professional equipment manufacturer engaged in box sealing machine and box opening machine.

Full range of models

Mainly include: semi-automatic box sealing machine, automatic box sealing machine, automatic folding cover sealing machine, corner edge sealing machine, e-commerce sealing machine, foam box sealing machine, I box sealing machine.

Stable performance

The company has professional technical and production team, many years of experience, many cases and practice.

Perfect after-sales system

The company has a professional service after-sales system, rapid response, to ensure 24-hour production safety of customers.

High performance / price ratio

Advanced technology and electrical configuration of well-known brands. Reasonable equipment price

Which one can sell automatic box opener, sealing machine or packing machine?

You can take a look at Zhongke Tiangong 3C automatic packing machine, which is used in the online packing of mobile phone production line, cosmetics production line and boxed products. Automatically complete a series of automatic production operations, such as automatic unpacking, automatic bottom sealing, automatic packing, automatic partition, automatic packing, automatic sealing, automatic marking, automatic output, etc., which greatly reduces the dependence of automatic production line on labor and reduces labor costs. Improve production efficiency.

What can the sealing machine do?

The sealing machine is mainly suitable for the sealing and packaging of cartons, which can be used not only on a single machine, but also with an assembly line. It can also be used as a packaging assembly line with carton forming and opening machine, packing machine, labeling machine, baling machine, pallet stacking machine, transportation and other equipment.

What are the main categories of box sealing machines

One-shaped box sealing machine, I-shaped box sealing machine, automatic folding cover sealing machine, automatic box opening machine,

Dongguan Meiyi sealing machine manufacturer to answer for you, hope to adopt!

This is the end of the introduction about the box opening machine, the box sealing machine and the automatic box sealing machine. I wonder if you have found the information you need? If you want to know more about this, remember to collect and follow this site.
