A list of the contents of this article:
- 1 、Specific operation flow of automatic packing machine
- 2 、What’s the difference between a carton winding machine and a packing machine?
- 3 、What is the function and principle of the baler?
- 4 、Classification of automatic binding machine
- 5 、Who knows what a packing machine is and what it is for?
- 6 、What are the advantages of automatic packing machine
Specific operation flow of automatic packing machine
The Boris automatic packing machine grasps and puts the bottle by the grip clamp, grasps and loads the bottle and box reliably, and realizes automation and action coordination through the combination of four-bar mechanism, movement, landing and electric control.
What’s the difference between a carton winding machine and a packing machine?
The working principle of the winding machine is to place the wound object in the center of the turntable, start the turntable motor to rotate, and naturally drive the turntable to rotate, so that the object can realize the peripheral winding film machine. At the same time, the lift motor also starts, driving the whole assembly of the winding and binding machine to move up and down to achieve the winding in the height direction of the object, which realizes the winding packaging of the whole appearance of the object. This is not only conducive to the packaging requirements of goods storage, transportation and mechanized loading and unloading operations, but also prevent the damage of goods in the handling process, play the role of dustproof, moisture-proof and cleaning, but also reduce production costs and improve production efficiency. In the winding process, the main thing is to adjust the tension of the film and penetrate the film. Generally, the degree of film tension can be achieved by adjusting the speed of the turntable and the speed of the motor. As long as you know that the rotating speed of the turntable is greater than the speed of the motor, the tighter the film will be, and the looser the principle is, it is not difficult to operate.
A packing machine is a kind of equipment that semi-automatically or automatically loads unpackaged products or small packaged products into transport packaging. Its working principle is to pack the products into boxes (corrugated cartons, plastic boxes, pallets) according to a certain arrangement and quantity, and close or seal the opening of the box. According to the requirements of the packing machine, it should have the functions of carton forming (or opening carton), measuring and packing, and some are also equipped with sealing or bundling functions.
Suzhou Jiajun is honored to answer for you and hope to adopt it.
What is the function and principle of the baler?
First, the working principle of the packing object is basically in the middle of the baling machine, first the right acrosome rises, the front end of the belt is pressed, the belt is tightened and tied on the object, and then the left acrosome rises, pressing the appropriate position of the lower belt, the heating sheet extends into the middle of the two belts, the middle top knife rises, cuts off the belt, and finally sends the next bundle of straps in place to complete a working cycle. 2. The work flow belt is sent in place → receives the binding signal → brake is released, the main motor starts (1) the → right top knife rises, and the right band is held up at the skateboard (2) the → “T” guide plate retreats (3) the → proximity switch senses the unwinding probe (4) the → main motor stops, and the brake suction (5) the → baler unwinding motor rotates. Unwind belt 0.35s (6) → belt tightens and binds to object (7) → main motor starts second, brake pulls in (8) → swing bar secondary pull belt, tightens belt (9) → left acrosome rises, presses lower belt (10) → heating piece extends into the middle of two belts (11) top knife rises in →, cuts off belt (12) → drops (13) top knife rises again in → Make the two belts firmly bonded (14) → top knife down, left and right top knife down at the same time (15) → heating plate reset (16) → slide plate back (17) → “T” guide plate reset (18) → proximity switch senses feed belt probe (19) → belt feed motor starts, drive belt feed belt (20) → large pendulum rod reset (21) → belt is in place Lead the lead on the “T” guide plate (22) → proximity switch induces double probe (23) → main motor stop, brake suction (24) → Packer completes a working cycle for more details
Classification of automatic binding machine
Binding machine (1) is classified according to binding material
① plastic strapping machine. It is a binding machine for medium and small weight boxes. The plastic belt used is mainly polypropylene belt, but also nylon belt, polyester belt and so on.
② steel belt binding machine. It uses steel belt as binding material. Because of its high strength, it is mainly used for heavy, large packing boxes.
The binding machine (2) is classified according to the joint mode.
① welding binding machine. Because the plastic belt is easy to be heated and melted, it is more suitable for plastic belt joints. According to the different ways of heating, it can be divided into electric welding, ultrasonic welding, high frequency welding, pulse welding and so on.
② buckle binding machine. The utility model adopts a special buckle joint, which clamps and fastens the joint of the binding belt, and is mostly used for steel strip.
(3) classified according to structural characteristics.
① basic binding machine. It is a binding machine suitable for various industries, and its table height is suitable for standing operation. Mostly used in bundling, small packaging, such as cartons, calcium plastic boxes, books and periodicals, etc.
② side strapping machine. The joint part of the binding tape is carried out on the side of the package, and the countertop is lower. It is suitable for the binding of large or polluting packages, if antirust treatment is added, aquatic products and pickled products can be bound, and dustproof measures can be added to bind packages with more dust.
③ pressurized binding machine. For leather, paper products, knitted cotton fabrics and other soft, elastic products, in order to bind tightly, it must be pressed first and then tied up. There are two ways of pressurization: air pressure and hydraulic pressure.
④ opening and closing track binding machine. Its belt track frame can be opened and closed horizontally or vertically to facilitate the placement of various cylindrical or annular packages, and then the track is closed and bundled.
⑤ horizontal rail strapping machine. Its belt track is arranged horizontally, and the package is tied horizontally. It is suitable for horizontal binding such as pallet packages.
⑥ portable strapping machine. It is generally placed on the top of the package, and when the belt surrounds the package, the belt is tightened and locked with the machine. It is operated manually and is flexible and portable.
(4) classified according to the degree of automation
① manual binding machine. Rely on manual operation to achieve binding and locking, often with plastic straps. The utility model has the advantages of simple structure and light weight, and is suitable for the binding of large or small batch packages.
② semi-automatic binding machine. Use the conveying device to send the package to the binding station, then manually wind the belt around the package, and finally tighten and fix the belt. The utility model has a low countertop and is very suitable for the binding of large packages.
③ automatic binding machine. There is a belt track frame above the worktable, and when the package enters the binding station, the processes such as belt feeding and wrapping, belt tightening, fixed cutting and so on will be carried out automatically. The belt track frame of the machine is fixed, which is generally suitable for bundling packages with single size and large batches. When bundling, the movement and turning of the package need to be carried out manually.
④ automatic strapping machine. The machine automatically completes all the predetermined binding processes, including the movement and steering of packages, without human operation and assistance, and is suitable for the binding of large quantities of packages.
Who knows what a packing machine is and what it is for?
In the back-end packaging of food and beverage, the automatic packing machine automatically arranges the filled packaging, loads it into the open carton, and completes the self-adhesive sealing and other actions of the packing equipment.
The packing machine can be divided into fully automatic and semi-automatic packing machine. All the actions are completed automatically. The fully automatic packing machine adopts a new type of combined structure, including box forming device, whole line device, filling device and sealing device and other functional units, which complete the corresponding functional actions respectively, and each device is installed on the same mainframe. It is controlled by P.L.C + touch screen. Equipped with missing bottle alarm stop, no bottle without packing safety device. It is greatly convenient to operate, manage, reduce production personnel and labor intensity, and is an indispensable equipment for automatic scale production.
Packing machine can also be divided into: wrapped packing machine, pneumatic packing machine, grab packing machine, robot packing machine.
The wrapping packing machine adopts the falling packaging mode, occupies a small area, reduces the equipment investment cost, adopts the international design concept, the structure is more reasonable, the action is more light and stable, and the power consumption is lower.
The pneumatic packing machine has the advantages of small size, beautiful appearance, low energy consumption, stable operation and convenient operation. The conveyor is driven by imported rodless cylinder, which runs smoothly and has high controllability.
The packing machine with pneumatic and electric operation and packing mode has the advantages of compact structure, beautiful appearance, low energy consumption and stable operation. The driving device is a symmetrical double rocker arm, which is driven by Japanese MITSUBISHI servo motor or three-phase asynchronous motor and runs smoothly.
The robot packing machine is a set of intelligent control system which takes the robot as the running main body and is equipped with conveying and regularization auxiliary equipment to complete the product packing process. The robot packing system has many advantages, such as strong product adaptability, strong multi-specification compatibility, high operation efficiency, convenient system maintenance and so on. Compared with the conventional packing equipment, the robot packing system is simpler and faster.
What are the advantages of automatic packing machine
The boxing machine has the following characteristics:
The packing machine can arrange the products automatically according to the packing requirements.
The packing machine is novel in design and compact in structure.
The packing machine has a wide range of application and can be used for packing a variety of products.
The packing machine is especially suitable for matching with the packaging assembly line and is easy to move.
The packing machine is programmed by computer, which is easy to operate and stable.
Packing machine bottle class, box type bag class, barrel class series.
