A list of the contents of this article:
- 1 、Who knows what a packing machine is and what it is for?
- 2 、The difference between automatic drop packing machine and grab packing machine
- 3 、Working principle of automatic packing machine
- 4 、Specific operation flow of automatic packing machine
- 5 、Brother, I am a student of mechatronics. I am working on my graduation thesis on the design of bottle grabbing device for JXZ12/ 4 automatic packing machine. Can you give me some advice?
Who knows what a packing machine is and what it is for?
In the back-end packaging of food and beverage, the automatic packing machine automatically arranges the filled packaging, loads it into the open carton, and completes the self-adhesive sealing and other actions of the packing equipment.
The packing machine can be divided into fully automatic and semi-automatic packing machine. All the actions are completed automatically. The fully automatic packing machine adopts a new type of combined structure, including box forming device, whole line device, filling device and sealing device and other functional units, which complete the corresponding functional actions respectively, and each device is installed on the same mainframe. It is controlled by P.L.C + touch screen. Equipped with missing bottle alarm stop, no bottle without packing safety device. It is greatly convenient to operate, manage, reduce production personnel and labor intensity, and is an indispensable equipment for automatic scale production.
Packing machine can also be divided into: wrapped packing machine, pneumatic packing machine, grab packing machine, robot packing machine.
The wrapping packing machine adopts the falling packaging mode, occupies a small area, reduces the equipment investment cost, adopts the international design concept, the structure is more reasonable, the action is more light and stable, and the power consumption is lower.
The pneumatic packing machine has the advantages of small size, beautiful appearance, low energy consumption, stable operation and convenient operation. The conveyor is driven by imported rodless cylinder, which runs smoothly and has high controllability.
The packing machine with pneumatic and electric operation and packing mode has the advantages of compact structure, beautiful appearance, low energy consumption and stable operation. The driving device is a symmetrical double rocker arm, which is driven by Japanese MITSUBISHI servo motor or three-phase asynchronous motor and runs smoothly.
The robot packing machine is a set of intelligent control system which takes the robot as the running main body and is equipped with conveying and regularization auxiliary equipment to complete the product packing process. The robot packing system has many advantages, such as strong product adaptability, strong multi-specification compatibility, high operation efficiency, convenient system maintenance and so on. Compared with the conventional packing equipment, the robot packing system is simpler and faster.
The difference between automatic drop packing machine and grab packing machine
Drop type means that after accumulating a good quantity, open the load-bearing board and drop it into the carton to complete the packing; grasping is to lift the specified number of products through the grip or sucker, properly separate the interval between the products, and then put them into the carton. Are you looking for packing equipment?
Working principle of automatic packing machine
The automatic packing machine is used to complete the transportation package. it loads the finished packaging into the box according to a certain arrangement and quantity, and closes or seals the opening of the box. The Cartoning machine is a machine used for product sales and packaging. it puts a measured quantitative material into a box and closes or seals the opening of the box.
working principle
The automatic packing machine automatically arranges the packaging, loads it into the open carton, and completes the self-adhesive sealing and other actions of the packing equipment, all the actions are completed automatically. Most automatic packing machines adopt a new type of combined structure, including box forming device, whole line device, filling device and sealing device and other functional units, which complete the corresponding functional actions respectively, and each device is installed on the same mainframe. The box billet of the box forming device is on the top, the filling device is directly below the box forming device, the whole row device is in front of the filling device, and the sealing device is behind the filling device. It is controlled by P.L.C + touch screen. Equipped with missing bottle alarm stop, no bottle without packing safety device. It is greatly convenient to operate, manage, reduce production personnel and labor intensity, and is an indispensable equipment for automatic scale production.
Brief introduction
The packing machine is used to complete the transportation package. it loads the finished packaging into the box according to a certain arrangement and quantity, and closes or seals the opening of the box. The Cartoning machine is a machine used for product sales and packaging. it puts a measured quantitative material into a box and closes or seals the opening of the box. Both the packing machine and the packing machine have the functions of forming (or opening the container), measuring, loading, sealing and so on. Hangzhou Yongchuang Machinery Co., Ltd. specializes in producing packing machine, soft bag packing machine, automatic packing machine, semi-automatic packing machine, pillow bag automatic packing machine series products.
Packing machine
In the automatic packaging assembly line, the packing machine is the core of the whole line system operation. Although the packaging machinery is not a direct production machine, it is necessary to realize production automation.
The main production of the packing machine runs smoothly and reliably, the packing effect is firm and beautiful, and the configuration is high. The main components selected from international famous brand equipment are easy to operate and easy to maintain.
Extraction packing machine, used for single or bundle products into the conveyor belt and stacked into cartons, sealed with self-adhesive tape.
classification
Specializing in the production of packing machine, packing machine, soft bag packing machine, automatic packing machine, semi-automatic packing machine, pillow bag automatic packing machine series products.
Automatic packing machine is a kind of intelligent automatic packing machine, which uses high-speed distribution device to pack all kinds of containers, plastic flat bottles, round bottles, irregular bottles, glass bottles of all sizes, round bottles, oval bottles, square cans and paper cans. in addition, it is also suitable for packing boxes with dividers. The bottle body is clamped by the bottle clip (built-in rubber to prevent damage to the bottle body) and put into the open carton. When the grip is lifted, the carton is discharged and sent to the sealing machine, which is controlled by P.L.C + touch display screen. Equipped with missing bottle alarm stop, no bottle without packing safety device. This assembly line is greatly convenient for operation, management, reducing production personnel and labor intensity, and is an indispensable equipment for automatic scale production.
● can arrange the products automatically according to the packing requirements.
● is novel in design and compact in structure.
● has a wide range of applications and can be used for packing a variety of products.
● is especially suitable for matching with packaging lines and is easy to move.
● computer program-controlled, easy to operate, stable action.
● bottle class, box bag class, bucket series.
Specific operation flow of automatic packing machine
The Boris automatic packing machine grasps and puts the bottle by the grip clamp, grasps and loads the bottle and box reliably, and realizes automation and action coordination through the combination of four-bar mechanism, movement, landing and electric control.
Brother, I am a student of mechatronics. I am working on my graduation thesis on the design of bottle grabbing device for JXZ12/ 4 automatic packing machine. Can you give me some advice?
Let’s take a look at what automatic control is.
Closed-loop control to complete
With reference to a bottle-grabbing process, it is realized according to the control theory learned. Add plc programming if necessary
This is the end of the introduction of the bottle packing machine. Thank you for taking the time to read the contents of this site. Don’t forget to look for more information about the manufacturer of the grab automatic packing machine and the bottle packing machine on this site.
