A list of the contents of this article:
- 1 、How does the automatic box sealing machine work?
- 2 、What is a box sealing machine?
- 3 、What is the difference between the left and right drive sealing machine and the automatic sealing machine?
- 4 、Main classification of box sealing machines
- 5 、What are the main categories of box sealing machines
How does the automatic box sealing machine work?
There are many manufacturers of sealing machines, but their working principles are all the same. Let’s take (Liyue packaging) automatic sealing machine as an example: seal the upper and lower bottom of the packaging carton with tape. The automatic sealing machine can also automatically adjust the height and width of different packaging sizes, which is suitable for mass production. After the product is boxed, it is sent to the sealing machine through the conveyor chain (belt, roller) and submitted to the box conveying mechanism. The box belt clamps the two sides of the carton and moves forward. The front short tongue is automatically bent by the tongue pressing rack, and the rear short tongue is automatically bent by the tongue holder when the carton enters the supporting roller of the sealing machine, there is a detection signal (photoelectric signal) to inform the action of the tongue cylinder, and there is a signal to inform the glue melting machine to spray glue automatically. The carton continues to move forward, and the left and right long tongues automatically bend to the middle through the guide bar, while pressing the box mechanism belt, pressing the left and right long tongues of the carton synchronously, so that the box, tongue and glue are glued together to complete the sealing and shaping movement. that is, the last process of product packaging-automatic sealing.
What is a box sealing machine?
First, the principle of box sealing machine
The use of instant adhesive tape sealing carton, economic fast, easy to adjust, can complete the upper and lower sealing action, can also use printing tape, but also can improve the product image, is the first choice of automatic packaging enterprises. The key component of the box sealing machine is the driving motor. The greater the motor power, the better.
Second, the structure of the box sealing machine
The main structural components of the automatic box sealing machine are composed of aircraft head, base, control panel, width adjustment handle, height adjustment handle and movement. The sealing machine adopts the sealing packaging of the carton seal with adhesive tape, which can not only be used in stand-alone packaging, but also can be equipped with assembly line for back-packing. The principle of the automatic folding cover sealing machine adopts the form of left and right drive, pneumatic folding mechanism, trapezoidal screw width adjustment mechanism and high strength structure design, which makes the machine reliable and can adapt to the continuous heavy sealing work of the production line.
3. Characteristics of automatic box sealing machine
1. The structure of the box sealing machine uses screws and chains to synchronously adjust the width and width.
two。 The use of imported box sealing machine accessories of a new type of patent tape sticker, no blower blowing tape, the use of patent pressing device, so that the tape upright will not bend, resulting in can not be pasted, sealing packaging is convenient.
3. The width of the belt is designed for better grip. Ring buckle type connection design, there will be no degumming fracture, sealing machine to change the belt is very easy, convenient and fast.
4. Sealing belt manufacturers independently innovate large-scale transmission wheel design, increase the bending Radian, increase the belt contact area, the belt will not skid, and the service life increases, the sealing machine technology is very mature. The main transmission mechanism of professional sealing machine uses special Peilin seat with high precision and low noise to increase the service life of the belt.
5. The corner length of the tape at both ends of the carton can be adjusted.
6. The box sealing machine factory designs a series of non-tape alarm, which opens the door and stops automatically to ensure the safety of maintenance.
For more information, please refer to Yongchuang sealing machine.
What is the difference between the left and right drive sealing machine and the automatic sealing machine?
The left and right drive sealing machine uses BOPP adhesive tape as the sealing material, which can seal the cartons in the upper and lower “one” shape at the same time, and the belts driven by motors on both sides can automatically correct and transport the cartons, which is fast and stable when sealing, and is suitable for heavier and wider cartons. When the auxiliary wheels on both sides assist the machine to seal the box, the middle seams are concentrated without cracking. The height of the table and the width and height of the carton can be adjusted independently, simple and practical. Elegant and generous shape, equipped with blade protection device to avoid accidental stabbing during operation. The parts are stable and durable and have a long service life. The fuselage comes with four high-strength brake wheels, so it is very convenient to transposition.
Main classification of box sealing machines
The sealing machine adopts instant adhesive tape to seal the carton, which is economical, fast and easy to adjust, can complete the upper and lower sealing action at one time, and can also use printing tape, which can improve the product image and is the first choice of automatic packaging for enterprises. It can be divided into semi-automatic sealing machine, pneumatic sealing machine, manual sealing machine, tape sealing machine, automatic bottom sealing machine, automatic sealing machine, four-corner sealing machine, folding cover sealing machine, corner sealing machine, side sealing machine and so on. The sealing machine produced is light and durable and easy to operate. Power source: 1p 110V 50Hz/60Hz 200W
Speed: 30 cases / min
Sealing size: L150-∞ W120-480H130-480 (mm)
Tape size: 48×72 (mm)
Kraft paper tape, BOPP tape
Machine size: L1090mm x W880mm x H1165mm
Transport size: L1628mm x W930mm x H1265mm
Gross weight / net weight: 220kg/170kg FX-03
* Power source: 1P 110V/220V 50Hz/60Hz 300W/470W
* Speed: 30 cases / min
* sealing size: L150 ~ ∞ W120mm 480H1200480 (mm)
* Tape size: 48mm 72 (mm) Kraft paper tape, BOPP tape
* Machine size: L1090mm x W890mm x H1280mm
* Transport size: L1200mm x W1050mm x H1435mm
* gross weight / net weight: 250kg/200kg. The folding cover sealing machine is suitable for automatically folding the upper cover of a certain specification carton and then sealing the upper and lower boxes with self-adhesive tape. in addition to manually adjusting the size of the carton, it can automatically fold the upper cover and seal the carton.
Machine characteristics
The main results are as follows: 1. Using high-strength grip PVC tape to drive both sides of the carton, the transmission runs smoothly and the tape is centering on the box.
2. it can be adjusted according to the size of the carton and realize the folding of the front, rear and side covers of the upper cover and the action of loading and unloading the carton.
3. It is the first in China to use pneumatic device to realize the automatic folding of the upper back cover and the side cover of the carton.
4. The tape sealing is smooth, firm, standardized and beautiful, and will not tear the box.
Product parameters
Conveying speed: 15m/min
Maximum packing size: W500 × H500mm
Minimum packing size: W150 × H120mm
Power supply: 220v/50-60Hz
Power consumption: 180W
Tape width: 48 60pm 76mm
External dimension: 1700 × 950x1690mm
Gas source: 5Kg/cmsup2
Machine weight: 250kg. Product characteristics
The main results are as follows: 1. The corner edge sealing machine is designed to be easy to operate, economical and durable, safe and the lowest failure rate.
2. Adjust the width and height of the machine manually according to the carton specifications.
3. Suitable for sealing cartons of the same specification at the same time
4. After the carton is sealed up and down in the middle of the front sealing machine, it enters the 90-degree corner machine, and the pushing plate is pushed into the sealing mechanism of the corner sealing machine.
5. the upper and lower corners of the carton are automatically sealed and smoothed at the same time; the sealing is beautiful, fast, labor-saving and efficient.
6. Install blade protection device to avoid accidental stabbing during operation.
Product parameters
FXJ-JB01
* Power source: 1p 110V/220V 50Hz/60Hz 1000W
* Speed: 12-15 cases / min
* sealing size: L200-500W350-700H200-500 (mm)
* Tape size: 48mm 72 (mm) Kraft paper tape, BOPP tape
* Machine size: L2200mm x W1280mm x H1400mm
* Transport size: L2250mm x W1330mm x H1600mm
* Gross weight / net weight: 550kg/480kg is manufactured by Taiwan technology and uses imported parts, electrical components and pneumatic components.
Adjust the width and height manually according to the carton specification
Suitable for cartons with side openings, such as beverages, floor tiles, etc.
Upper and lower belt drive, sealing on both sides, economical, fast and smooth
Equipped with knife protection device to avoid accidental stabbing during operation
It can work on a stand-alone machine, or can be used with an automatic assembly line.
FXJ-5050
* Power source: 1p 110V/220V 50Hz/60Hz 400W
* Speed: 12-15 cases / min
* sealing size: L200-550W150-480H127480 (mm)
* Tape size: 48mm 72 (mm) Kraft paper tape, BOPP tape
* Machine size: L1850mm x W988mm x H1370mm
* Transport size: L2000mm x W1050mm x H1570mm
* Gross weight / net weight: 360kg/300kg
Product name: FX-02 automatic folding cover sealing machine Technical parameters: power source: 1p 110V/220V 50Hz/60Hz 200W/400W Speed: 15 boxes / packing box size: L150 ~ ∞ W12000H1200450 (mm) Tape Dimensions: 48mm 72 (mm) Kraft Paper Tape, BOPP Tape Machine Dimensions: L1150mm x W1005mm x H1230mm Transport Dimensions: L1200mm x W1100mm x H1400mm Gross weight / net weight: 230kg/250kg
Detailed introduction:
When the automatic folding cover sealing machine cooperates with the assembly line operation, it is only necessary to fold the four bendable panels formed on the bottom surface of the carton, put the articles into the conveying track driven by belts on both sides, and the carton folding cover device on the upper side of the sealing machine starts, folding and sealing the box is completed at one time. When the size of the carton changes, the fully automatic machine positioning, automatic top folding, automatic timely transmission, no manual care, suitable for connecting to the automatic production line. Machine description:
GPA-50 left and right drive box sealing machine | one word sealing machine
1. Components:
The use of international advanced finishing equipment processing, selected international well-known brand accessories.
2. Technology:
Gurqi relies on more than ten years of independent R & D and design experience, and absorbs the advanced technology of international counterparts such as Japan and Germany in the sealing machine.
3. Appearance design:
① the dominant color of this sealing machine is beige, which is stylish and exquisite. The machine color suitable for the corresponding production line can also be configured according to the needs of customers.
② is light in size, complementary to pulleys and flexible in displacement, making it more convenient for installation and debugging.
4. Product technical parameters:
Product model: GPA-50
Conveying speed: 0-20m/min
Maximum packing size: l ∞ × W500 × H500mm
Minimum packing size: L150 × W150 × H120mm
Power supply: 220amp 380V 50Hz
Consumption function: 240W
Applicable tape: W48mm/60mm/75mm
Machine size: L1020 × W850 × H1350 (excluding front and rear roller frame)
Machine weight: 120kg
5. Powerful function of reasonable optimization:
① adjusts width and height manually according to carton specifications, which is simple, fast and convenient.
② belt drive on both sides, upper and lower sealing, economical, fast and smooth
6. industry-leading sealing performance:
① has stable performance, reliable quality, high sealing efficiency, strong applicability and long service life.
② is suitable for sealing light cartons after packing, and the sealing effect is smooth, standardized and beautiful.
③ adopts instant tape sealing, which is economical, fast and easy to adjust, and can complete the upper and lower sealing action at one time.
7. Protection design:
The performance of ① parts is precise and durable, the structure design is strict, the operation process is vibration-free, and the operation is stable and reliable.
② is equipped with blade protection device to avoid accidental stabbing during operation, safe production and efficient packaging. Tape sealing machine refers to the sealing of cartons with instant adhesive tape, which is economical and easy to adjust. It can complete the action of upper and lower sealing at one time, and printing tape and box opener can also be used to improve the product image. It is the first choice of automatic packaging enterprises. The key component of the box sealing machine is the driving motor. The greater the motor power, the better.
Characteristics of adhesive tape sealing machine:
1. The sealing machine is suitable for sealing and packing cartons, and can be used either individually or with an assembly line. it is suitable for chemical fiber industry, tobacco rebaking industry, pharmaceutical industry, publishing industry, refrigeration and air conditioning industry, home appliance industry, ceramic industry, food industry and so on.
two。 This sealing machine adopts instant adhesive tape to seal the carton, which is economical and easy to adjust. It can complete the upper and lower sealing action at one time, and the printing tape can be used to improve the product impression.
Technical parameters
Maximum sealing size: 500 × 600mm
Minimum sealing size: 150 × 90mm
Sealing tape width: 36mm, 48mm, 60mm
Workbench height: 500-750mm
Use tape: BOPP, Kraft paper, PVC tape
Sealing speed: 20 cartons / min (TEUs)
Power supply: 220V 50HZ 180W
External dimension: 1500 × 740 × 1425mm
Weight: 120kg function: ① automatically adjusts width and height according to different carton specifications
② side drive ten upper belt drive, suitable for heavy-duty, large carton use, to ensure that the upper and lower box sealing smoothly and quickly
③ stand-alone operation, suitable for small batch, multi-specification production.
Technical parameters
Conveying speed: 0-20m/min
Maximum packing size: l ∞ × W500 × H500mm
Minimum packing size: L150 × W150 × H150mm
Power supply: 220amp 380V 50Hz
Consumption function: 360W
Applicable tape: W48mm/60mm/75mm
Machine size: L1170 × W900 × H1350 (excluding front and rear roller frame)
Machine weight: 180kg
What are the main categories of box sealing machines
Divided by glue: one-shaped sealing machine, four-corner sealing machine, I-shaped sealing machine, three-shaped sealing machine and Wang sealing machine
According to the function, the one-word sealing machine can be divided into: the sealing machine with automatic folding cover and the sealing machine without automatic folding cover.
This is the end of the introduction about the left and right sealing machine and what the sealing machine is. I wonder if you have found the information you need? If you want to know more about this, remember to collect and follow this site.
