Automatic Low Level Palletizer

While every palletizer is pre-programmed with unit sizes and pallet modes to match your immediate requirements, it is easy to add new configurations and modes on the operator console.

Offers a complete commodity infeed and pallet dump alternative, as well as numerous orientation and stacking options for palletizing

Although this palletizer operates on the ground, it can accept boxes from all levels. Thus, you can enjoy the benefits of low level operation with low, medium or high level feeds.

The palletizer’s clearing, open construction and ground access points simplify routine maintenance. Field operation allows plant staff to monitor the operation of the palletizer while performing other tasks.

The color display shows instant operating data information and allows individual operation of all palletizing functions, diagnostics and changeover settings. It provides easy-to-follow sequences for fully automatic and manual functions, and automatic settings for daily, shift or high-volume operations.

Preventive maintenance messages automatically alert operators to scheduled or routine maintenance.

The palletizer is designed for reliable and powerful load transfer, with mechanical row push rods with double chain drive. It uses a load-bearing lift table to ensure stable product transfer and to remove pressure on the drive motor, thereby increasing motor life.

The vertical transport is driven by a variable frequency motor, which clears the shock to the equipment by providing soft start and termination in the load transport chain.

Fully automatic feeding timing belt controls box spacing and feeding to achieve reasonable orientation, row and gap configuration.

Skewed, reinforced transfer table ensures easy layer transfer

The stainless steel plate structure reinforced lifting platform is specially designed for long distance transportation. Heavy-duty stainless steel plate transfer plates are supported by cross-bar reinforcement beams, reducing case friction and removing bench load stress for case palletizing.

Self-adjusting layer holder sweep bars on the palletizer compensate for case load variations to ensure a positive sweep for every load. It will drop each layer onto the tray on its own, clearing up the extra adjustments during the transform.
