Vertical box opener (diagram of the use of automatic box opener)

A list of the contents of this article:

What is the box opener?

The automatic box opener automatically completes the opening, forming and folding of the bottom folded leaves. And now complete the lower part of the tape paste, the machine will automatically open the cardboard box board, the bottom of the box is converted according to a certain procedure, and sealed with tape and transported to the special equipment of the packing machine.

The main principle of the box opener: first, put the flat carton on the storage tank (which can store 100 cartons), suck the carton out of the trough through the sucker, shape the carton at the same time, fold the front and back and left and right covers, and finally complete the bottom sealing of the tape. The whole action is completed automatically.

Features of the opening machine equipment: vertical cardboard storage mode is adopted, which can be supplemented at any time without stopping; it is suitable for packaging of the same carton size at the same time, if the carton specification needs to be changed, it can be manually adjusted and used (the time required is only 1: 2 minutes); this machine adopts reasonable design, suction box, forming and bottom sealing are all handled automatically in one go. The machine performance is precise and durable, the operation process is non-vibration, the operation is stable and long life; this machine adopts PLC+ man-machine interface display screen control, high performance, high speed, high efficiency; carton sealing tape corner length 50~70mm, customizable 80mm, 100mm; can be used stand-alone or with automatic packaging assembly line.

Equipment parameters of box opener:

Work rate: single phase 220V, 50Hz/60Hz, 600W

Air pressure: 6 kg / square centimeter

Tape width: 4.8-6.0cm

Molding speed: 12 cases / min

Carton size: maximum size: L550mm W400mm H400mm

Minimum size: L200mm W150mm H100mm

Machine weight: about 400kg

With or without tape and no cardboard box alarm function

If you need more details, you can also click: automatic box opener (for reference)

6453478c8ccdc

Classification and characteristics of injection molding machines

According to the arrangement of injection device and mold locking device, the injection molding machine can be divided into vertical type, horizontal type and vertical-horizontal compound type. Their respective characteristics are as follows:

(1) the characteristics of the vertical injection molding machine:

1. The injection device and the mold locking device are located on the same vertical centerline, and the mold is opened and closed along the upper and lower direction. Its area is only about half that of a horizontal machine, so it is about twice as productive in terms of floor space.

2. It is easy to realize the forming of inserts. Because the mold surface is facing up, it is easy to position the insert. By using the machine with fixed lower template and movable upper template, the fully automatic forming of embedded parts can be easily realized if the belt conveying device is combined with the manipulator.

3. The weight of the mold is supported by the horizontal template to open and close up and down, which is similar to that of the horizontal machine, which is caused by the gravity of the mold, which makes the template unable to open and close. It helps to maintain the accuracy of machinery and mold for a long time.

4. Each plastic cavity can be taken out by a simple manipulator, which is beneficial to precision molding.

5. The general mold locking device is open and easy to configure all kinds of automatic devices, which is suitable for the automatic forming of complex and exquisite products.

6. The drawing belt conveying device is easy to be installed in the middle of the mold, and it is convenient to realize automatic production.

7. It is easy to ensure the consistency of resin fluidity and mold temperature distribution in the mold.

8. Equipped with rotating table, mobile table and inclined table, it is easy to realize insert forming and in-mold combination molding.

9. In small batch trial production, the mold is simple in structure, low in cost, and easy to uninstall.

10. Having withstood the test of many earthquakes, the vertical machine has better earthquake resistance than the horizontal machine because of its low center of gravity.

(2) the characteristics of horizontal injection molding machine:

1, that is, because of the low fuselage of the mainframe, there is no height restriction for the factory building.

2. When the product can be dropped automatically, it can be formed automatically without the use of a manipulator.

3. Because the fuselage is low, the supply is convenient, and the maintenance is easy.

4. The mold needs to be installed by crane.

5. under the juxtaposition of multiple sets, the molded products are easy to be collected and packaged by the conveyor belt.

How to adjust the feed of vertical molding machine?

Operation method: 1. Select a suitable wrench, measure the thickness of the mold, and estimate the thimble stroke of the mold. 2. adjust the distance between the mold device and the template. 3. Operate the mold until the end. 4. Shut down the machine and install the mold on the board. 5. The mold locking pressure and speed can be adjusted according to the actual injection demand, and there is no fixed requirement. 6. Tighten the fixed screw of the mold again, debug the stroke of the machine and the working efficiency of each system.

What is a fully automatic carton forming machine

What is a fully automatic carton forming machine? The fully automatic carton forming machine is what we call the box opener. Do you understand the automatic carton forming machine? In the process of packaging production, a series of operations such as out of the box, forming, folding and so on can be produced automatically, and the tape seal at the bottom of the carton can be realized at the same time, according to the packing procedure from the distributed sealing belt to the packaging device, the packaging device is essential for the modernization of large-scale production automation enterprises.

What exactly is the function of the box opener?

The box opener is a fully automatic equipment which automatically operates the carton, converts the bottom of the carton according to a certain procedure, and seals it with adhesive tape and transmits it to the packing machine through the conveyor belt. The machine has a high degree of automation and simple operation, and can automatically complete a series of work, such as box picking, forming, folding cover, bottom sealing and so on. It has developed rapidly in the packaging machinery industry. The workload of operators and the number of operators are reduced. At the same time, the occupation space of machinery is reduced, and the cost of purchasing other auxiliary machinery is saved. Save the cost of workers and improve the production efficiency of enterprises. Learn more about automatic box opener Shanghai trek intelligent equipment

This is the end of the vertical introduction of the unpacking machine. Thank you for taking the time to read the contents of this site. Don’t forget to look for more information about the use of diagrams and vertical openers on this site.
