Article catalogue:
- 1 、What is the principle of metal crusher operation?
- 2 、How to operate the scrap iron and steel crusher?
- 3 、Explain in detail the working principle and structure of scrap crusher
What is the principle of metal crusher operation?
The working principle of the metal crusher is as follows: using the basic principle of hammering, driven by a high-speed and high-torque motor, the hammerhead on the main rotor alternately hits the objects to be broken into the cavity, through the space formed between the lining plate and the hammerhead, the objects to be broken can be fully and effectively broken in the crushing cavity, and the objects to be broken will be torn into pieces in accordance with the specifications. The broken material passes through the air rotary sorting system to separate metals and non-metals. in addition, the whole system is equipped with dust removal device to minimize the harm of dust pollution produced in the production process. The equipment mainly has the advantages of high output, low energy consumption, high efficiency, uniform discharge and so on, and the equipment has the advantages of low noise, no pollution, simple operation and convenient maintenance. If you are a customer of metal crusher, or if you have any problems in the use of metal crusher, we will provide you with a professional solution for metal crusher application free of charge! Call immediately to learn more. I believe that communication with “emerging” people will be helpful to your choice! You can also log on to our website:
Gongyi Xinxing Machinery Factory
How to operate the scrap iron and steel crusher?
Scrap crusher is a kind of crushing machine used to produce scrap materials, which is mainly used for scrapping cars, household appliances and light scrap. Scrap crushing processing is the use of crusher to crush scrap, the use of sorting system to sort the broken scrap to get a pure and high-quality scrap processing method. Its working principle is that under the continuous drive of high-speed and high-torque motor, the hammerhead on the crusher rotor alternately hits the scrap into the cavity, and under the strong impact, the scrap is torn and extruded into a certain specification of broken steel, and then treated by the sorting equipment, the high-quality broken steel with high purity can be obtained.
Scrap iron crusher is a kind of crusher, which is used to crush scrap iron materials, which belongs to medium-sized metal crusher.
The material falls vertically into the high-speed rotating impeller from the upper part of the scrap iron crusher machine, and under the action of high-speed centrifugal force, it produces high-speed impact and crushing with another part of the material shunted around the impeller in the form of an umbrella. After the material collides with each other, the material will be crushed by eddy current between the impeller and the housing for many times, and will be discharged directly from the lower part, forming a closed circuit cycle for many times. The required particle size of the finished product is controlled by the screening equipment.
Explain in detail the working principle and structure of scrap crusher
In the scrap metal crushing production line, the scrap crusher is one of the main equipment. The crusher is mainly used to break light and thin metal plates into small pieces, such as waste car bodies, to facilitate sorting and get purer ferrous metal raw materials. At the same time, the scrap metal crushed by the crusher is also easy to transport and return to the furnace. The following is mainly through the picture and text driving to explain the structure and working principle of the crusher.
The structure of the crusher is shown in the figure. The hammerhead is hinged to the hammer disc with a hammer shaft, and the hammer disc is assembled on the spindle. The working principle of the crusher is to impact the material with a high-speed rotating hammer. because the impact time between the crusher hammer and the material is very short, it will produce a great impact, so that the material will be broken along the fragile parts such as natural fissures, bedding plane and joint plane. When the hammerhead hits the sheet, when the shear stress caused by the magnetic impact is larger than the shear strength limit, the material will have shear failure, and the hammerhead will tear it into small pieces along the shear seam and bring it into the cavity between the rotor and the liner. During the rotation of the crusher spindle, the hammerhead constantly strikes the material in the chamber.
This is the end of the video introduction on the working principle of the scrap crusher and the working principle of the scrap crusher. Do you know if you have found the information you need? If you want to know more about this, remember to collect and follow this site.
